Surface Hub 2 Smart Camera
TECH SPEC
| Dimensions | 43mm high (54.6mm high with foot) x 67mm wide x 66mm deep (42mm wide foot) |
| Memory | 1 GB DRAM, 8 GB eMMC (None user accessible) |
| Processor | Intel Myriad X 2085 (Image Signal Processor and NN SOC with 1 TFLOPS of DNN acceleration and 18 cores) |
| Security | Camera software updatable through Windows Update via Hub Software updates protected by signature security process |
| Software | Built-in functionality: “Auto framing” (automatically frames people in field of view) Image optimization (auto exposure, auto white balance, anti-flicker) Tilt angle adapting de-warp/un-distortion for natural faces across the field of view Upgradability: Internal Camera firmware can be updated with new functionality or bug fixes through Windows Update |
| Sensors | Sensor Resolution: 4K |
| What’s in the box | Surface Hub 2 Smart Camera with privacy cover Quick Start Guide Safety and warranty documents |
| Weight | 180g (0.4 lb) with Camera Cover |
| Connections | Mounting: Top of Surface Hub 2S 85” and 50” only Mechanical & Electrical Interface to Hub: USB-C break-away magnetic attach to top of bezel Interface to Surface Hub 2S 85”and 50”: Customized USB-C Reversible USB-C connection: Not supported Hub Rotation: Not supported |
| Cameras, video, and audio | Fixed focus lens with 11 glass elements 1 RGB Camera Module Working Distances: 1.0 – 7.4m HFOV: 136 degrees Tilt range: +20deg and -20deg from horizontal. Surface Hub 2 Smart Camera adapts its de-warp mesh to un-distort the image according to the camera tilt angle, so the image always looks natural. Video Format: 16:9 (NV12 at 360p, 720p, 1080p, 1440p) Privacy cover magnetically attaches to front of camera for privacy, and magnetically attaches to back of camera for convenient storage |
| Exterior | Casing: Anodized Aluminum Color: Platinum Physical buttons: None One white LED indicator for camera status (indicator is only visible when ‘On’) |
| Warranty | 1-year limited hardware warranty (All Countries) |
